| TYPE | DESCRIPTION |
| Architecture | Current FB |
| Number of channels | 2 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) | 5 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) | 12 |
| GBW (typ) (MHz) | 370 |
| BW at Acl (MHz) | 370 |
| Acl, min spec gain (V/V) | 1 |
| Slew rate (typ) (V/µs) | 600 |
| Vn at flatband (typ) (nV√Hz) | 4.3 |
| Vn at 1 kHz (typ) (nV√Hz) | 4.3 |
| Iq per channel (typ) (mA) | 1 |
| Vos (offset voltage at 25°C) (max) (mV) | 3 |
| Rail-to-rail | No |
| Rating | Catalog |
| Operating temperature range (°C) | -40 to 85 |
| CMRR (typ) (dB) | 60 |
| Input bias current (max) (pA) | 4000000 |
| Offset drift (typ) (µV/°C) | 0 |
| Iout (typ) (mA) | 110 |
| 2nd harmonic (dBc) | 65 |
| 3rd harmonic (dBc) | 63 |
| Frequency of harmonic distortion measurement (MHz) | 5 |
| Architecture | Current FB |
| Number of channels | 2 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) | 5 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) | 12 |
| GBW (typ) (MHz) | 370 |
| BW at Acl (MHz) | 370 |
| Acl, min spec gain (V/V) | 1 |
| Slew rate (typ) (V/µs) | 600 |
| Vn at flatband (typ) (nV√Hz) | 4.3 |
| Vn at 1 kHz (typ) (nV√Hz) | 4.3 |
| Iq per channel (typ) (mA) | 1 |
| Vos (offset voltage at 25°C) (max) (mV) | 3 |
| Rail-to-rail | No |
| Rating | Catalog |
| Operating temperature range (°C) | -40 to 85 |
| CMRR (typ) (dB) | 60 |
| Input bias current (max) (pA) | 4000000 |
| Offset drift (typ) (µV/°C) | 0 |
| Iout (typ) (mA) | 110 |
| 2nd harmonic (dBc) | 65 |
| 3rd harmonic (dBc) | 63 |
| Frequency of harmonic distortion measurement (MHz) | 5 |
 | |
