| TYPE | DESCRIPTION |
| Architecture | FET / CMOS Input, Voltage FB |
| Number of channels | 1 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) | 6 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) | 12.6 |
| GBW (typ) (MHz) | 390 |
| BW at Acl (MHz) | 800 |
| Acl, min spec gain (V/V) | 1 |
| Slew rate (typ) (V/µs) | 1000 |
| Vn at flatband (typ) (nV√Hz) | 4.5 |
| Vn at 1 kHz (typ) (nV√Hz) | 7.5 |
| Iq per channel (typ) (mA) | 23.5 |
| Vos (offset voltage at 25°C) (max) (mV) | 0.25 |
| Rail-to-rail | No |
| Features | Shutdown |
| Rating | Catalog |
| Operating temperature range (°C) | -40 to 105 |
| CMRR (typ) (dB) | 110 |
| Input bias current (max) (pA) | 20 |
| Offset drift (typ) (µV/°C) | 1 |
| Iout (typ) (mA) | 80 |
| 2nd harmonic (dBc) | -100 |
| 3rd harmonic (dBc) | -120 |
| Frequency of harmonic distortion measurement (MHz) | 1 |
| Architecture | FET / CMOS Input, Voltage FB |
| Number of channels | 1 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) | 6 |
| Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) | 12.6 |
| GBW (typ) (MHz) | 390 |
| BW at Acl (MHz) | 800 |
| Acl, min spec gain (V/V) | 1 |
| Slew rate (typ) (V/µs) | 1000 |
| Vn at flatband (typ) (nV√Hz) | 4.5 |
| Vn at 1 kHz (typ) (nV√Hz) | 7.5 |
| Iq per channel (typ) (mA) | 23.5 |
| Vos (offset voltage at 25°C) (max) (mV) | 0.25 |
| Rail-to-rail | No |
| Features | Shutdown |
| Rating | Catalog |
| Operating temperature range (°C) | -40 to 105 |
| CMRR (typ) (dB) | 110 |
| Input bias current (max) (pA) | 20 |
| Offset drift (typ) (µV/°C) | 1 |
| Iout (typ) (mA) | 80 |
| 2nd harmonic (dBc) | -100 |
| 3rd harmonic (dBc) | -120 |
| Frequency of harmonic distortion measurement (MHz) | 1 |
 | |
